Visual work
More screen area for documents, media review, dashboards and content-rich applications.
Extra-large workspace platform
S18D
S18D
An 18.5-inch IPS platform for customers who prioritise visible workspace, multi-window productivity and a desktop-style laptop experience.
Display1920 × 1200 IPS
ProcessorIntel Core i3-10100Y
Memory16GB DDR4
Storage256GB / 1TB SSD
Market position
Maximum workspace in a portable format.
S18D brings an 18.5-inch IPS panel to a laptop form factor, creating a visibly differentiated option for project buyers and distributors. The large display is suited to customers who spend more time working at a desk but still need an integrated, movable device.
Multi-window productivity
An extra-large display gives customers more room to arrange parallel tasks and supporting tools.
Desktop-style channels
A distinctive fit for buyers who prioritise screen size over ultra-compact portability.
Platform highlights
Scale up the visible workspace.
The reference platform combines an 18.5-inch IPS display, Intel Core i3-10100Y performance, 16GB DDR4 memory and fanless passive cooling. Availability, storage configuration, MOQ and delivery timing are confirmed against live stock and the project plan.
Feature
Specification
Application
Display
18.5-inch IPS
Extra-large workspace
Memory
16GB DDR4
Everyday multitasking
Storage
256GB / 1TB SSD
Channel flexibility
Cooling
Fanless passive
Quiet operation
Final commercial terms and specifications are confirmed in the quotation and approved sample.
Technical overview
Core specifications.
Specifications below describe the current reference platform. Project requirements and model-specific documentation should be confirmed before ordering.
Display
- Screen
- 18.5-inch IPS
- Resolution
- 1920 × 1200, 60Hz
- Touch
- Non-touch
- Colour gamut
- 100% sRGB
- Brightness
- 230 nits
- Opening angle
- 180 degrees
Performance & storage
- Processor
- Intel Core i3-10100Y
- Graphics
- Intel UHD Graphics 615
- CPU configuration
- 2 cores / 4 threads
- Frequency
- 1.3GHz, up to 3.9GHz
- Memory
- 16GB DDR4
- Storage
- 256GB / 1TB M.2 2280 SATA SSD
Connectivity & ports
- Wireless
- Dual-band 2.4GHz / 5GHz Wi-Fi
- Bluetooth
- Bluetooth 5.2
- USB
- 3 × USB 3.2 Gen 1
- Video
- 1 × Mini HDMI
- Type-C
- Full-featured PD support
- Other ports
- Audio and DC-in
Physical & power
- Battery
- 8000mAh Li-polymer
- Cooling
- Fanless passive cooling
- Material / colour
- ABS plastic / grey or black
- Keyboard
- Full-size, non-backlit
- Camera & audio
- 2.0MP camera, speakers, microphone
- Dimensions
- 428.6 × 282.4 × 20.2 mm
- Weight
- Approx. 2.56 kg
OEM & project options
Adapt the platform to your channel.
Available customisation depends on quantity, current materials and the approved project scope. We confirm feasibility before quotation and sampling.
Project path
Move from requirement to confirmed product.
Each stage is tied to the actual specification, quantity and market rather than a generic promise.
01RequirementMarket, specification, quantity and target timing.
02QuotationConfiguration, availability and commercial conditions.
03Sample & approvalProduct details and project presentation confirmed.
04FulfilmentProduction or stock coordination, inspection and shipment.
Enquire about S18D
Share your target quantity and market.
We will confirm the suitable storage option, current availability and next steps.
